Professional Laminated Machine Double Layer Glass Deep Processing Manufacture Furnace

1 / 5

Professional Laminated Machine Double Layer Glass Deep Processing Manufacture Furnace

Customization:	Available
Certification:	CE, FDA, ISO
Control System:	PLC Control

Send Inquiry

Product Description

Basic Info

Model NO.

BL2SS-2030

Glass Thickness

8-40 mm

Max Glass Size

1900*2900mm

Silicone Bag Size

2000*3000mm

Total Power

42kw

Power Supply

380V/50Hz

Process Time

40-100min

Origin

China

Production Capacity

2000 Sets/ Year

Package Size

200.0x200.0x200.0cm

Product Description

Detailed Photos

Our Advantages

Furnace Body

Adopts newest custom encryption composite board as insulation for improved mechanical strength and thermal performance.

Heating Element

304 stainless steel heating tubes ensure longer service life, fast and equal heating.

PLC Control System

Full automatic PLC control system via touch screen for effortless parameter management.

Silicone Bag

3mm thickness with resistance up to 180°C. High tear and aging resistance for high seal vacuum rating.

Product Parameters

Items	Spec.	Power Supply	Total Power (KW)	Silicone Bag Size (MM)	Max Glass Size (MM)	Overall Dimension (MM)	Bag Qty
BL2SS-2030	Single station, 2 layers	380V/50HZ	27	2000*3000	1900*2900	780025001590	2
BL4DD-2030	Double stations, 4 layers	380V/50HZ	27	2000*3000	1900*2900	1220025001590	4
BL2SS-2638	Single station, 2 layers	380V/50HZ	42	2600*3800	2500*3700	940031001590	2
BL4DS-2638	Double stations, 4 layers	380V/50HZ	42	2600*3800	2500*3700	1460031001590	4
BL2SS-2650	Single station, 2 layers	380V/50HZ	48	2600*5000	2500*4900	1180031001590	2
BL4DS-2660	Double stations, 4 layers	380V/50HZ	60	2600*6000	2500*5900	2120031001590	4

Packaging & Shipping

Factory Overview

Certifications

Frequently Asked Questions

What glass thickness can this machine process?

The machine is capable of processing glass thicknesses ranging from 8mm to 40mm.

How does the PLC control system benefit the operation?

The full automatic PLC control system provides a user-friendly touch screen interface, making it very easy to set parameters and monitor the production process.

What measures are in place for sudden power failures?

The vacuum pump is connected to buffer irrigation, which ensures that the vacuum state is maintained even in the event of a sudden power outage.

What are the specifications of the silicone bag?

It has a 3mm thickness and can withstand temperatures up to 180°C. It features high tear and aging resistance for long-term service life.

What kind of heating elements are used in the furnace?

We use 304 stainless steel heating tubes, which offer fast and uniform heating along with a longer operational life.

What products are available in your equipment range?

Our range includes EVA/PVB Laminated Glass lines, Insulated Glass lines, Cutting, Washing, and Edging machines, as well as tempering furnaces and storage systems.
