Automatic Gas-Filled Insulating Glass Machine for Insulating Glassproduction Line with Insulating Glass Sealing Robot 2800*5000mm

1 / 5

Automatic Gas-Filled Insulating Glass Machine for Insulating Glassproduction Line with Insulating Glass Sealing Robot 2800*5000mm

Customization:	Available
Certification:	CE, FDA, ISO, PCI, PDA, UR, UL
Control System:	PLC Control

Send Inquiry

Product Description

ℹ️

Basic Information

Model NO.

BLBG2850

Glass Thickness

12-80mm

Max Glass Size

2800*5000mm

Min Glass Size

280*450mm

Washing Speed

2-12m/Min

Working Speed

2-40m/Min

Capacity

80 Sets Per Month

HS Code

8464901900

⚙️

Product Description

Automatic Gas Filling Insulating Glass Processing Machine

Our Insulating Glass Machine can be upgraded and customized to meet specific production requirements. It is designed for high-efficiency manufacturing of double glass, triple glass, and structural glass facade units.

PLC control touch screen human-machine interface.
Automatic identification of coated glass and LOW-E glass film layer.
Imported vacuum generator and suction cup for superior glass handling.
Three pairs of glass cleaning brushes with frequency conversion drive.
Digital controlled assembling line to improve efficiency and save production time.
Stainless steel cleaning machine construction with durable plastic spraying finish.
Main electric appliances selected from famous international brands.
Automatic energy-conservation system with intelligent dormancy state.

📊

Technical Parameters

Item	BLBG3060	BLBG2850	BLBG2540	BLBG2030
Total power	90KW	70KW	46KW	36KW
Max glass size	3000*6000mm	2800*5000mm	2500*4000mm	2000*3000mm
Min glass size	280*450mm	280*450mm	280*450mm	280*450mm
LG unit thickness	12~80mm	12~80mm	12~40mm	12~40mm
Working Speed	2-45m/min	2-45m/min	2-45m/min	2-40m/min

📸

Detailed Photos

🏭

Certifications & Support

❓

Frequently Asked Questions

How do you ensure the quality of the glass processing machines?

We always provide a pre-production sample before bulk production and conduct a strict final inspection before shipment to guarantee stable product quality.

What types of glass can this production line process?

The line is designed for double glazing, triple glazing, shaped insulating glass, and can automatically identify coated and LOW-E glass layers.

Is the machine energy efficient?

Yes, it features an automatic energy-conservation discontinuity working system where sections not in use automatically switch to an intelligent dormancy state to reduce power consumption.

What are the main products available?

We specialize in Insulated Glass Production Lines, Glass Cutting Machines, Washing Machines, Edging Machines, Tempering Furnaces, and Laminated Glass Production Lines.

What kind of after-sales service do you provide?

With over 20 years of production experience, we have a professional engineering and after-sales service team to support customers globally.

What delivery and payment terms are accepted?

We accept various delivery terms including FOB, CFR, CIF, EXW, and DDP. Payments can be made via T/T, L/C, Credit Card, or PayPal in USD, EUR, or CNY.
