| Model | ZNJ 2025 | ZNJ 2030 | ZNJ 2535 |
|---|---|---|---|
| Power | 7KW | 7KW | 10KW |
| Air pressure | 0.5~0.7Mpa | 0.5~0.7Mpa | 0.5~0.7Mpa |
| Gas consumption | 0.8 m3/min | 0.8 m3/min | 0.8 m3/min |
| Maximum glue pressure | 35Mpa | 35Mpa | 35Mpa |
| Maximum glass size | 2000×2500mm | 2000×3000mm | 2500×3600mm |
| Maximum glass weight | 200kg | 200kg | 300kg |
| Glass thickness | 12~56mm | 12~56mm | 12~56mm |
| Machine Weight | 3500-3900Kg | 3700-4100Kg | 4500-4900Kg |
| Name | Brand | Remarks |
|---|---|---|
| Servo Systems | YASKAWA | Japan |
| IO input / output module | MSYSTEM | Japan |
| Linear Guides | Pepper star / ABA | China |
| Power Supply | Ming wei | Taiwan, China |
| Electronic Tape Adjustment | NOVOTECHNIK | Germany |
| Low voltage electrical | SCHNEIDER / LS | France / South Korea |
| Pneumatic components | AIRTAC | Taiwan, China |
| Touch Screen | KINCO | China |
| Hydraulic proportional valve | HNC / Ward | Taiwan, China |
A leading single source provider of high-quality flat glass processing machinery, service, and supplies. We continue to search for the most innovative and reliable equipment for fabricating, handling, and processing flat glass. Each machine is characterized by innovative features, long-lasting durability, and high reliability.
As a partner for glass processing solutions, we source and supply an extensive range of machinery including integrated units for insulated glass manufacturing, window and door fabrication, and façade manufacture.
