Oil Cutter Automatic Float Glass Cutting Machine Table with High Efficiency PLC Control Low-E Film Removal

Customization:	Available
Certification:	CE, ISO, SGS
Cutting Method:	Oil Cutter Cutting

📑 Basic Info.

Specification	Detail
Model NO.	DS-CT10037
Maximum Cutting Thickness	20 mm
Power Supply	380V 50Hz
Safety Features	Emergency Stop Button, Overload Protection, Safety Sensor
Machine Type	Glass Cutting Table
Max. Loading/Cutting Glass Size	10000 X 3700mm
Cutting Thickness	5 - 25mm
Cutting Precision	±0.30mm
Max. Cutting Speed	1800m/Min
Vacuum Pressure	-70~-99 Kpa
Number of Breaking Bars	1+2
Compressed Pressure	0.6MPa
Power	13kw
Voltage/Frequency	Customized
Transport Package	Container
Specification	40HQ
Production Capacity	120

💎 Product Description

DS-CT10037 Industrial Glass Cutting Table - Enter the Realm of Jumbo-Scale Glass Processing

The DS-CT10037 glass cutting table marks the entry into true industrial-scale fabrication, offering an incredible 10-meter cutting length designed to process jumbo stock sheets with ease. It combines massive capacity with the ability to cut heavy-duty glass up to 25mm thick, providing the power and scale needed to service the most demanding clients in the industry.

✔

Automatic Cutting Pressure Regulation: Intelligent system dynamically adjusts for any glass thickness (2-25mm), ensuring a perfect score every time.

✔

High-Efficiency Bidirectional Cutting: Maximizes throughput by optimizing the cutting path, slashing cycle times.

✔

Versatile Cutting Mastery: Masterfully handles both high-speed straight-line cutting and intricate shape cutting.

📏 DS-CT Series Specifications

Model	Max Cutting Sheet	Cutting Precision	Cutting Thickness	Max Cutting Speed
DS-CT2621	2600 × 2100mm	± 0.15mm	2 - 19mm	180m/min
DS-CT3725	3700 × 2500mm	± 0.15mm	2 - 19mm	180m/min
DS-CT4228	4200 × 2800mm	± 0.20mm	2 - 19mm	180m/min
DS-CT5133	5100 × 3300mm	± 0.25mm	3 - 25mm	180m/min
DS-CT7537	7500 × 3700mm	± 0.25mm	5 - 25mm	180m/min
DS-CT10037	10000 × 3700mm	± 0.25mm	5 - 25mm	180m/min
DS-CT18037	18000 × 3700mm	± 0.25mm	5 - 25mm	180m/min

⭐ Core Advantages

World-Class Components
Integration of premium brands including Delta Tau motion controllers and Panasonic servo motors.

Advanced Direct-Drive System
Dual-drive linear rail replaces traditional belt systems, increasing speed and precision.

Exclusive Bidirectional Cutting
Proprietary technology minimizes travel distance and improves output efficiency.

🚀 Application Scenarios

Architectural & Facade Glass

Photovoltaic & Technical Glass

Advanced Automotive Glazing

❓ Frequently Asked Questions

1. What types of glass can your machine cut?

Our machines are engineered to cut a wide variety of glass, including float, Low-E, coated, and mirrored glass, in thicknesses ranging from 2mm to 25mm.

2. What is the maximum sheet size it can handle?

We offer a range of models, from standard 4200mm x 2800mm tables to custom solutions processing immense 18-meter glass sheets.

3. How accurate is the cutting?

We guarantee a cutting accuracy of ±0.15 mm. This level of precision ensures flawless edges for downstream processes like tempering or laminating.

4. Is the machine difficult to operate?

No. It features an intuitive touchscreen interface, supports direct CAD/CAM file imports, and includes automatic nesting software to optimize material usage.

5. What certifications does your equipment have?

All our machines are CE certified, and our manufacturing processes are ISO 9001 certified. Official SGS inspection reports are also available.

6. How long does installation and training take?

Standard installation is typically completed in 2-3 days, followed by 1-2 days of comprehensive operator training.
